Earth (Ground) Label (IEC5017a-)
Part Number: IEC5017a-
Lead Time:
Select material and size to see lead time

Earth (Ground) Label (IEC5017a-)

Part Number: IEC5017a-
Lead Time:
Select material and size to see lead time

SKU:
IEC5017a-
Item Description:
Earth (Ground) Label
Language:
English
Signal Word:
None
Symbols:
I5017a
Starting Price:
$0.71
Format:
Symbol Only
Hazard Type:
IEC
Hazard Type:
No Hazard Type
Hazard Avoidance:
No Hazard Avoidance
Object:
Grounded Connection
Object:
IEC Symbol
Body Part:
No Body Part
Product Type:
Label
Video Vimeo:
https://player.vimeo.com/video/50607115
View Data Sheets and Specifications For Material ()
View Dimension Guide For Size ()



Description


Clarion Safety Systems brings you high quality earth safety labels (ITEM# IEC5017A-) which are produced on premium polyester material and are expertly designed to meet your general electrical hazard labeling needs. This label features a symbol-only design to identify earth (ground) connection points on electrical equipment — critical for ensuring proper operation and safety in systems that require fault current grounding. It helps maintenance teams, installers, and inspectors quickly identify grounding terminals and contributes to safer, code-compliant installations across industrial and commercial applications.

Standards and Compliance

This label is designed to meet IEC 60417 standards for electrical equipment markings, featuring the standardized “Earth Ground” symbol in a square format for consistent, internationally recognized communication. Its use aligns with global best practices for equipment labeling and electrical system safety. Need assistance interpreting standards or labeling electrical panels properly? Our team is here to help with application guidance and technical support.

Message Details

This symbol-only label supports clear visual communication and fast identification of grounding points. It features:

  • Word Message: No Word Message
  • Signal Word: None
  • Symbol: IEC5017A
  • Symbol Meaning: Earth Ground

Sizes

Available in five standard square sizes to suit a wide range of electrical enclosures, panels, and machinery:

  • Size A: 3.00” x 3.00”
  • Size B: 2.00” x 2.00”
  • Size C: 1.50” x 1.50”
  • Size D: 0.75” x 0.75”
  • Size E: 0.375” x 0.375”

Materials

Choose from three durable, high-performance materials to meet your environment-specific needs. All are manufactured using premium 3M adhesive systems and tested for industrial conditions:

  • P – Indoor Polyester: Engineered for interior use on electrical panels and control systems. Excellent chemical and abrasion resistance with a service temperature range from –40°F to 300°F.
  • B – Outdoor Polyester: UV-, moisture-, and abrasion-resistant for both indoor and outdoor use. Performs in temperatures from –40°F to 175°F and withstands washdowns, oils, and harsh conditions.
  • T – Anodized Aluminum: Rigid aluminum label with high-temperature resistance (–40°F to 450°F). Ideal for rugged or high-heat applications, including power systems and industrial controls. Features a high-performance 3M acrylic adhesive for long-term bonding.

Need help determining the right material for your project or equipment surface? We’re here to help with recommendations, spec sheets, and installation tips.

Why Choose Clarion Safety

Clarion Safety labels are trusted by electrical engineers, OEMs, and industrial facility managers for consistent, high-quality performance. With every Clarion label, you benefit from:

  • IEC-compliant designs for global electrical marking standards
  • Premium 3M-based materials for durability and adhesion
  • Broad material and size options to meet your exact specification needs
  • Fast turnaround times for urgent production and field requirements
  • Expert customer service trained in standards and application strategy

Clearly mark earth ground terminals with durable, symbol-based labels built to perform. Choose the IEC5017A- label from Clarion Safety to enhance clarity, compliance, and equipment safety in your electrical systems.




Material Information


To view all material information, please visit our Safety Resources.

Material Name Application MaxTemp (°F) MinTemp (°F) Chemical Resistance Water Resistance UV Resistance ROHS CROHS REACH Expected Life Indoor Expected Life Outdoor Material Data Sheet Regulatory Data Sheet
Outdoor Polyester (B) Outdoor 175° -40° Excellent - - Yes Yes Yes - - PDF Download Material Data Sheet PDF Download Regulatory Data Sheet
Indoor Polyester (P) Indoor 300° -40° Excellent - - Yes Yes Yes - - PDF Download Material Data Sheet PDF Download Regulatory Data Sheet
Anodized Aluminum (T) Indoor / Outdoor 450° -40° Excellent - - Yes Yes Yes - - PDF DownloadMaterial Data Sheet PDF DownloadRegulatory Data Sheet

Bulk Pricing Information


Part Number Material Size SKU
Loading bulk pricing...

Reviews


2 Reviews
Write a Review

  • 5
    perfect :)

    Posted by Lubo Ovsak on 1st Apr 2022

    perfect :)

  • 5
    Excellent Customer Service!

    Posted by SAM GUILBEAU on 9th Nov 2020

    Excellent Customer Service!
